Sony FCB-EV9500M Camera, 1080p60 HD, 1/1.8" STARVIS CMOS, 30x Optical Zoom, VISCA Control, MIPI Output

FCB-EV9500M Spec Sheet
FCB-EV9500M Technical Manual

The Sony FCB-EV9500M Camera delivers professional-grade 2.1 MP resolution with 1080p/60 HD video output. Featuring a 1/1.8" STARVIS CMOS sensor and 30x optical zoom, it ensures high-clarity imagery even in low-light conditions. Equipped with advanced Super Image Stabilization, the camera produces steady footage with minimal blur, making it ideal for security, surveillance, robotics, and industrial monitoring applications. Multiple output options, including MIPI and LVDS, provide flexible integration into diverse systems.

Designed for demanding environments, the FCB-EV9500M offers superior performance with low-light sensitivity down to 0.009 lx, True Wide Dynamic Range (WDR), digital 2D/3D noise reduction, and motion detection. Robust construction, wide operating temperature range, and VISCA protocol support ensure reliable, high-performance operation in professional applications.

Features:

• Super Image Stabilizer for clear, stable footage
• 30x optical zoom, 36x enhanced stable zoom, 12x digital zoom
• 1/1.8" STARVIS CMOS sensor, 2.1 MP
• Low-light performance: 0.009 lx (ICR-Off mode)
• Wide Dynamic Range (WDR)
• Digital 2D/3D noise reduction
• Motion detection with alerts
• Privacy zone masking and spherical masking
• MIPI and LVDS outputs
• VISCA protocol camera control
• Picture effects: E-Flip, Mirror, Black & White, Color Enhancement
• Electronic/slow shutter, TTL signal-level control

Applications:

• Surveillance: Indoor and outdoor security systems
• Traffic Monitoring: High-clarity capture in dynamic environments
• Remote Monitoring: Long-distance observation with reliable video quality
• Video Conferencing: Professional-grade visuals
• Inspection Robots: Precise imaging for robotics and automation
• UAVs/Drones: Compact form factor for aerial applications
