Sony FCB-EV9500L Camera, 1080p60 HD, 1/1.8" STARVIS CMOS, 30x Optical Zoom, VISCA Control

FCB-EV9500L Spec Sheet
FCB-EV9500L Technical Manual

The Sony FCB-EV9500L Camera is engineered for professional-grade surveillance, industrial inspections, robotics, and broadcasting. Equipped with a 1/1.8" STARVIS CMOS sensor delivering 2.1 MP resolution, it provides crisp 1080p video at 60fps. The camera features 30x optical zoom with 36x enhanced stable zoom and 12x digital zoom, ensuring detailed observation across a wide range of distances. Advanced image processing including True WDR, 2D/3D noise reduction, and motion detection ensures clarity even in challenging lighting conditions.

Designed for low-light environments, the FCB-EV9500L achieves a minimum illumination of just 0.009 lx in ICR-Off mode. Its robust construction, wide operating temperature range, and integration with VISCA control protocols make it a reliable solution for demanding applications where precision and flexibility are required.

Features:

• 1/1.8" STARVIS CMOS sensor, 2.1 MP
• 30x optical zoom, 36x stable zoom, 12x digital zoom
• True Wide Dynamic Range (WDR)
• Advanced image stabilization (EIS)
• Low-light performance: 0.009 lx (ICR-Off)
• Noise reduction: 2D/3D
• Motion detection and alarm
• Privacy zone masking
• Multi-output: HDMI, LVDS
• VISCA protocol camera control
• Picture effects: E-Flip, Mirror, Black & White, Color Enhancement
• Electronic/slow shutter, TTL signal-level control

Applications:

• Surveillance: High-clarity monitoring in indoor/outdoor environments
• Industrial Inspection: Detailed imaging for quality control and production
• Robotics: Precision vision with zoom and stabilization
• Broadcasting: High-definition, low-light capable video capture
• Drones: Stable aerial footage in dynamic environments
• Traffic Monitoring: Clear imaging for traffic management systems
• Scientific Research: Accurate documentation and analysis
