Ricoh FL-HC1214-2M Lens
Regular price
$338.00
Shipping calculated at checkout.
The 12 mm focal length and format sizes range between 1/4, 1/3, 1/2 and 2/3” allowes the Ricoh FL-HC1214-2M to offer great optics for industrial and machine vision applications as well as small and microscopic inspection applications.
--
With locking focus and iris screws, the 2 Mega-Pixel FL-HC1214-2M has an iris range of 1.4 m to 16. It boasts the small size of φ29.5 x 28.5 mm and 55 grams and has a C-Mount compatibility for ease of use.
Free shipping within the US. One (1) year warranty.
| Formate Size | 1/2, 1/3" |
| Focal Length | 12 mm |
| Max. Aperture Ratio | 1：1.4 |
| Iris Range | 1.4～16 |
| Mount | C |
| HAV 1/3" Format | 21.9° |
| HAV 1/2" Format | 28.9° |
| HAV 1/1.8" Format | - |
| HAV 2/3" Format | - |
| Minimum Object Distance | 0.25 m |
| Filter Size | 27 P=0.5 mm |
| Back focal length | 11.50 mm |
| Dimensions | φ29.5×28.5 mm |
| Weight | 55 ｇ |
| Remarks | Focus & Iris lock screws |
