Ricoh FL-CC0815B-VG Lens
Regular price
$225.00
Shipping calculated at checkout.
All purpose applications such as pattern matching, component positioning, missing-part inspection, board mounting, inspection of pharmaceuticals, produce, and grains are just a few examples of the range in applications the Ricoh FL-CC0815B-VG-AVP is outfitted to tackle and do it well.
--
This lens is standard as well in machine vision uses and compatible with VGA class of cameras. Locking screws provide extra vibration control measures for precision application and weighs only 120 grams and is 42x40 mm in dimensions, allowing you to conveniently place anywhere needed for your application.
Free shipping within the US. One (1) year warranty.
| Format Size | 2/3, 1/2, 1/3" |
| Focal Length | 8.5 mm |
| Max Aperture Ratio | 1:1.5 |
| Iris Range | 1.5-Close |
| Mount | C |
| HAV 1/4" Format | 24.0° |
| HAV 1/3" Format | 31.9° |
| HAV 1/2" Format | 42.1° |
| HAV 2/3" Format | 56.5° |
| Minimum Object Distance | 0.2 m |
| Back Focal Length | 10.88 mm |
| Filter Size | 40.5 P=0.5 mm |
| Dimensions | φ42x40 mm |
| Weight | 120 g |
| Remarks | Focus & Iris lock screws |
