KT&C ATC-HZ5230T-LCN 1/2.8" STARVIS CMOS Rolling Shutter Block Camera, 2.13MP, 1080P60, 30x Optical Zoom

$0.00

Shipping calculated at checkout.

The KT&C ATC-HZ5230T-LCN is a high-performance HD-SDI block camera designed for professional surveillance applications. Equipped with a 1/2.8" SONY STARVIS CMOS sensor, it delivers 2.13MP resolution at 1080P60, ensuring clear and detailed images.

The camera features a 30x optical zoom lens, providing flexible focal length options for various monitoring needs. Its rolling shutter technology offers efficient image capture, making it suitable for dynamic environments. The compact design allows for easy integration into existing systems, making it an ideal choice for both indoor and outdoor surveillance.

Features:

Image Sensor: 1/2.8" SONY STARVIS CMOS
Effective Pixels: 2.13MP (1945 x 1097)
Video Output: HD-SDI
Resolution: 1080P60
Zoom: 30x Optical Zoom
Shutter Type: Rolling Shutter
Lens: 4.3mm to 129mm
Minimum Illumination: 0.1 Lux (Day), 0.05 Lux (Night)
WDR: True Wide Dynamic Range
Noise Reduction: 3D DNR, Defog
Remote Control: UART RS232-TTL (Pelco-D, Pelco C, VISCA, Hitachi)
Power Supply: 12VDC (9V to 15VDC)
Power Consumption: Max. 6.4W
Operating Temperature: -10℃ to +50℃
Dimensions: 50 x 58.8 x 90.5 mm
Weight: Approx. 232g

Applications:

Airport Security
City Surveillance
Campus Security
Retail Security
Transportation Hubs
Critical Infrastructure
Public Events
Perimeter Security
Banking Sector
Highway Monitoring
Border Security
