Tamron MP3010M-EV Machine Vision & Surveillance Camera, 1080P60, Sony STARVIS™ Sensor, 10x Optical Zoom, HDMI/UVC/LVDS
MP3010M-EV Spec Sheet
The Tamron MP3010M-EV is a compact, high-performance camera module designed for professional applications including industrial automation, robotics, surveillance, video conferencing, and transportation systems. Featuring Sony STARVIS™ high-sensitivity CMOS sensor technology, it delivers HD video up to 1080p/60, capturing detailed imagery even in low-light conditions. Flexible connectivity options include LVDS, HDMI, and UVC outputs, providing compatibility with a wide range of systems and formats, including NTSC and PAL.
Equipped with 10x optical zoom (f=3.3–33mm), the module supports Enhanced Electronic Image Stabilization (EIS) for smooth video, Day/Night ICR switching, and VISCA™ protocol control via TTL/RS-232/RS-485. Advanced image processing features such as 16-step aperture control, 3D + 2D noise reduction, and defogging ensure high-quality visuals across challenging environments. Lightweight at approximately 70g and rated for operation from -5°C to 60°C, the MP3010M-EV is ideal for versatile, 24/7 monitoring applications.
Features:
- Sony STARVIS™ high-sensitivity CMOS sensor for clear low-light imaging
- HD video output up to 1080p/60; supports NTSC/PAL, LVDS, HDMI, UVC (UVC up to 1080/30p)
- 10x optical zoom with fast auto/manual/one-push focus
- Enhanced Electronic Image Stabilization (EIS)
- Day/Night (ICR) switching
- VISCA™ protocol compatibility via TTL/RS-232/RS-485
- Advanced image processing: 16-step aperture, 3D+2D noise reduction, defog
- Lightweight and compact: ~70g module
- Operating temperature: -5°C to 60°C, humidity: 30–80%
Applications:
- Industrial Automation
- Robotics
- Surveillance Systems
- Video Conferencing
- Transportation Monitoring
- Machine Vision
