Ricoh FL-YFL3528, 35mm Lens
Regular price
$1,872.00
Shipping calculated at checkout.
The ultra-high resolution, minimal distortion Ricoh FL-YFL3528-AVP Line Scan Lens is perfect for applications such as inspections of all kinds including steel and other metals, pulp, fiber and/or textile. film and other various applications dealing with flat materials.
--
Available in F-Mount (bayonet mount) and PENTAX K mount (PENTAX bayonet mount) configurations and suitable for sensors up to 45mm, this is the perfect lens for any industrial application or inspection of various flat materials that need to be precise.
Free shipping within the US. One (1) year warranty.
| Format Size | 45mm Image Circle |
| Focal Length | 35 mm |
| Max. Aperture Ratio | 1:2.8 |
| Iris Range | 2.8-22 |
| Mount | F-mount (bayonet mount) FL-YFL3528
K-mount (PENTAX bayonet mount) FL-YKL3528 |
| Field of View - 4,096x7µm | 57 mm (Magnification: 0.5x) |
| Field of View - 7,450x4.7µm | 70 mm (Magnification: 0.5x) |
| Field of View - 4,096x10µm | 81 mm (Magnification: 0.5x) |
| Minimum object distance | 0.19 m (Magnification: 0.5x) |
| Back focal length | 33.22 mm |
| Filter size | 62 P=0.75 mm |
| Dimensions | φ72x56.8 mm(FL-YFL3528)
φ72x57.8 mm(FL-YKL3528) |
| Min.~Max. Magnification | ∞ ~ 0.5X |
| Weight | 380 g |
| Remarks | Focus: Lock Screw Iris: Click stop.
Not for photographic cameras. |
